Depth:
84mm
Width:
45 mm
Length:
77mm
Series:
LC1D
Function:
Motor Control
Mount Type:
DIN Rail
Coil Voltage:
220 V ac
Power Rating:
5.5kW
Product Type:
Contactor
Terminal Type:
Screw
Contact Current:
12A
Contact Voltage:
690V
Number of Poles:
3
Standards/Approvals:
CCC, CSA, EAC, EN 60947-5-1, IEC, RoHS, UL
Better World Product:
Yes
Distrelec Product Id:
30150622
Contactor Application:
Motor Control, Resistive Load
Operational Current Ie:
12A
Control Circuit Voltage Uc:
220 V
Normal State Configuration:
3 NO
Number of Auxiliary Contacts:
2
Pole and Throw Configuration:
3
Maximum Operating Temperature:
60°C
Minimum Operating Temperature:
-5°C
Auxiliary Contact Configuration:
1 NO/1 NC
Better World Verification:
Green Premium
Better World Product:
Yes
Maximum Operating Temperature:
+60°C
Contact Current Rating:
12 A
Series:
LC1D
Minimum Operating Temperature:
-5°C
Coil Voltage:
220 V ac
Length:
77mm
Width:
45mm
Depth:
84mm
Number Of Auxiliary Contacts:
2
Normal State Configuration:
3NO
Range:
TeSys D
Power Rating:
5.5 kW
Contact Voltage Rating:
690 V ac
Number of Poles:
3
Terminal Type:
Screw
