Current Rating:
5.0A
Dimensions:
66.9 x 15.4 x 14.5mm
Mounting Type:
Panel Mount
Gender:
Female
Body Orientation:
Straight
Length:
66.9mm
D Connector Type:
Mixed Contact D-Sub
Housing Material:
Steel
Width:
15.4mm
Depth:
14.5mm
D-Sub Shell Size:
D
Mixed Contact Layout:
24W7
Contact Plating:
Gold
Termination Method:
Solder
Number of Contacts:
21
Maximum Operating Temperature:
+125°C
Minimum Operating Temperature:
-55.0°C
Contact Material:
Copper Alloy
Shell Size, Connector Layout:
5 (DD, D) - 24W7
Flange Feature:
Housing/Shell (Unthreaded)
HTSUS:
8536.69.8000
RoHS Status:
ROHS3 Compliant
Operating Temperature:
-55°C ~ 125°C
Connector Style:
D-Sub, Combo
Contact Finish Thickness:
-
Dielectric Material:
Polyester Thermoplastic, Glass Filled
Number of Positions:
24 (17 + 7 Coax or Power)
Voltage Rating:
-
REACH Status:
REACH Unaffected
Number of Rows:
2
Material Flammability Rating:
UL94 V-0
Package:
Bulk
Wire Gauge:
20 AWG
Contact Form:
-
Connector Type:
Receptacle, Female Sockets
Contact Finish:
-
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Termination:
Solder Cup
standardLeadTime:
29 Weeks
Current Rating (Amps):
5A
Backset Spacing:
-
Ingress Protection:
-
Features:
-
Mounting Type:
Free Hanging (In-Line)
Color:
Green
Series:
-
Shell Material, Finish:
Steel, Tin Plated
Contact Type:
Signal and Coax or Power (Not Included)
Contact Material:
-
ECCN:
EAR99
