Series:
7W2
Current Rating:
5.0A
Dimensions:
39.1 x 12.5 x 12.6mm
Mounting Type:
Panel Mount
Gender:
Female
Body Orientation:
Straight
Termination Method:
Solder
Length:
39.1mm
D Connector Type:
Mixed Contact D-Sub
Housing Material:
Glass Fibre Reinforced Thermoplastic
Width:
12.5mm
Depth:
12.6mm
Mixed Contact Layout:
5W2
Contact Plating:
Tin
Pitch:
2.84mm
Number of Contacts:
7
Maximum Operating Temperature:
+125°C
Minimum Operating Temperature:
-55.0°C
Contact Material:
Copper Alloy
Shell Size, Connector Layout:
2 (DA, A) - 7W2
Flange Feature:
Housing/Shell (Unthreaded)
HTSUS:
8536.69.8000
RoHS Status:
ROHS3 Compliant
Operating Temperature:
-55°C ~ 125°C
Connector Style:
D-Sub, Combo
Contact Finish Thickness:
30.0µin (0.76µm)
Dielectric Material:
Polyester Thermoplastic, Glass Filled
Number of Positions:
7 (5 + 2 Coax or Power)
Voltage Rating:
-
REACH Status:
REACH Unaffected
Number of Rows:
2
Material Flammability Rating:
UL94 V-0
Package:
Bulk
Wire Gauge:
20 AWG
Contact Form:
-
Connector Type:
Receptacle, Female Sockets
Contact Finish:
Gold or Gold-Palladium
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Termination:
Solder Cup
standardLeadTime:
8 Weeks
Current Rating (Amps):
5A
Backset Spacing:
-
Ingress Protection:
-
Features:
-
Mounting Type:
Free Hanging (In-Line)
Color:
Green
Series:
-
Shell Material, Finish:
Steel, Tin Plated
Contact Type:
Signal and Coax or Power (Not Included)
Contact Material:
-
ECCN:
EAR99
