Series:
0967
Current Rating:
7.5A
Dimensions:
12.5 x 31.2 x 18mm
Mounting Type:
Panel Mount
Voltage Rating:
1.0 kV
Gender:
Female
Body Orientation:
Straight
Termination Method:
Wire Wrap
Length:
31.2mm
Housing Material:
Metal
Width:
12.5mm
Depth:
18.0mm
Contact Plating:
Gold over Nickel
Pitch:
2.74mm
Number of Contacts:
9
Maximum Operating Temperature:
+150°C
Minimum Operating Temperature:
-55.0°C
Contact Material:
Copper Alloy
Shell Size, Connector Layout:
1 (DE, E)
Flange Feature:
Housing/Shell (Unthreaded)
HTSUS:
8536.69.4040
RoHS Status:
ROHS3 Compliant
Operating Temperature:
-55°C ~ 125°C
Connector Style:
D-Sub
Contact Finish Thickness:
-
Dielectric Material:
Polybutylene Terephthalate (PBT), Polyester, Glass Filled
Number of Positions:
9
Voltage Rating:
-
REACH Status:
REACH Unaffected
Number of Rows:
2
Material Flammability Rating:
UL94 V-0
Package:
Bulk
Wire Gauge:
-
Contact Form:
-
Connector Type:
Receptacle, Female Sockets
Contact Finish:
-
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Termination:
Wire Wrap
standardLeadTime:
8 Weeks
Current Rating (Amps):
-
Backset Spacing:
-
Ingress Protection:
-
Features:
-
Mounting Type:
Panel Mount, Through Hole
Color:
-
Series:
-
Shell Material, Finish:
Steel
Contact Type:
Signal
Contact Material:
Copper Alloy
ECCN:
EAR99
