Dimensions:
3 x 1.4 x 1mm
Maximum Collector Emitter Saturation Voltage:
-1 V
Maximum Collector Cut-off Current:
-100nA
Width:
1.4mm
Transistor Configuration:
Single
Maximum Continuous Collector Current:
-500 mA
Package Type:
SOT-23 (TO-236AB)
Number of Elements per Chip:
2
Maximum Operating Temperature:
+150 °C
Transistor Type:
PNP
Maximum Collector Base Voltage:
-80 V
Maximum Base Emitter Saturation Voltage:
-1.5 V
Maximum Emitter Base Voltage:
-10 V
Length:
3mm
Pin Count:
3
Minimum DC Current Gain:
2000
Mounting Type:
Surface Mount
Maximum Power Dissipation:
250 mW
Maximum Collector Emitter Voltage:
60 V
Height:
1mm
Minimum Operating Temperature:
-65 °C
