TDK-Lambda CCG15-30 30W DC-DC Converter PCB Mount, Voltage in 18, 76 V dc, Voltage out 15V dc

CCG30-48-15S TDK-Lambda CCG15-30 30W DC-DC Converter PCB Mount, Voltage in 18, 76 V dc, Voltage out 15V dc
TDK-Lambda

Product Information

Number of Outputs:
1
Output Voltage Adjustment Range:
13.5 → 16.5V dc
Load Regulation:
60mV
Isolation Voltage:
1.5kV
Output Current:
2A
Mounting Type:
PCB Mount
Package:
SMD
Maximum Temperature:
+85°C
Series:
CCG15-30
Input Voltage Range:
18 → 76 V dc
Isolated:
Yes
Railway Approved:
No
Width:
25.4mm
Depth:
25.4mm
Output Voltage:
15V dc
Medical Approved:
No
Minimum Temperature:
-40°C
Input Voltage Nominal:
18 V dc
Power Rating:
30W
RoHs Compliant
Checking for live stock

This is CCG15-30 30W DC-DC Converter PCB Mount Voltage in 18 76 V dc Voltage out 15V dc manufactured by TDK-Lambda. The manufacturer part number is CCG30-48-15S. Additionally, the product is supplied with 1 outputs. Load Regulation - 60mv. The product is available in pcb mount configuration. It is shipped in smd. The product ccg15-30, is a highly preferred choice for users. Furthermore, the product is 25.4mm wide. The product comes in 25.4mm depth.

pdf icon
Datasheet - CCG-30-48-15S(Technical Reference)
