Number of Rows:
2/3
Row Loading:
z/b/d
Current Rating:
6A
Minimum Operating Temperature:
-55°C
Voltage Rating:
500 V ac
Gender:
Female
Body Orientation:
Straight
Pitch:
3.81 mm, 5.08 mm, 6.5 mm, 10.16 mm
Termination Method:
Solder
Housing Material:
Thermoplastic
Maximum Contact Resistance:
8mΩ
Class Rating:
C2
Contact Plating:
Silver
Series:
09 06
Number of Contacts:
24 + 7
Type:
MH
Maximum Operating Temperature:
+125°C
Contact Material:
Copper Alloy
Style:
MH
HTSUS:
8536.69.4040
RoHS Status:
ROHS3 Compliant
Material - Insulation:
Polybutylene Terephthalate (PBT), Glass Filled
Operating Temperature:
-55°C ~ 125°C
Contact Finish Thickness:
-
Number of Positions:
31 (24 + 7 Power)
REACH Status:
REACH Unaffected
Number of Rows:
3
Material Flammability Rating:
UL94 V-0
Package:
Bulk
Connector Type:
Header, Male Pins and Blades
Contact Finish:
Gold or Gold-Palladium
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Level, Class:
2
Termination:
Solder, Quick Connect
standardLeadTime:
14 Weeks
Current Rating (Amps):
-
Features:
-
Mounting Type:
Panel Mount, Through Hole
Series:
DIN 41612
Pitch:
-
Number of Positions Loaded:
All
ECCN:
EAR99
