Number of Outputs:
1
Ripple And Noise:
<50mV
Output Current:
10A
Standards Met:
61000-4-4, 61000-4-5, 61000-4-6, CE Certified, cULus Listed, cULus Recognized, EAC, EN 50178/VDE 0160, EN 55022, EN 60204, EN 60950, EN 61000-3-2, EN 61000-4-11, EN 61000-4-2, EN 61000-4-3, EN 61000-4-8, IEC 1709, IEC 60068-2-27, IEC 60068-2-6, IEC 61204, IEC 61558-2-16, TUV, VDE 0100-410/DIN57100-410, VDE 0106-101
Mounting Type:
DIN Rail Mount
Maximum Temperature:
+70°C
Series:
PRO MAX
Electrical Phase:
3
Special Features:
Durable, High Performance
AC or DC Input Voltage:
ac, dc
Height:
130mm
Width:
60mm
Depth:
125mm
MTBF:
>500000h
Output Voltage:
24V dc
Minimum Temperature:
-25°C
AC or DC Output Voltage:
dc
Power Rating:
240W
Input Voltage:
320 → 575V ac
Manufacturer Standard Lead Time:
6 Weeks
Number of Outputs:
1
Detailed Description:
Enclosed AC DC Converter 1 Output 24V 10A 320 ~ 575 VAC, 450 ~ 800 VDC Input
Voltage - Isolation:
4kV
Features:
Adjustable Output, IP20
Mounting Type:
DIN Rail
Applications:
Industrial, ITE (Commercial)
Series:
PRO MAX3 (240W)
Voltage - Output 1:
24V
Size / Dimension:
4.92" L x 2.36" W x 5.12" H (125.0mm x 60.0mm x 130.0mm)
Efficiency:
91.5%
Power (Watts):
240W
Current - Output (Max):
10A
Approvals:
CE, cULus, cuRus, EAC, TUV
Voltage - Input:
320 ~ 575 VAC, 450 ~ 800 VDC
Operating Temperature:
-25°C ~ 70°C
Type:
Enclosed
Manufacturer:
Weidmuller
