Maximum Temperature:
+70°C
AC or DC Output Voltage:
dc
Minimum Temperature:
-25°C
AC or DC Input Voltage:
ac
Width:
54mm
MTBF:
2566680h
Electrical Phase:
1
Type:
Switch Mode
Load Regulation:
0.1%
Standards Met:
CB, CE Marked, CSA C22.2 No. 107.1, CSA C22.2 No. 60950, cULus, cURus Recognised, File E151273, File E197259, FM Approval, NEC Class 2, UL 508, UL 60950
Efficiency:
87.1%
Input Voltage:
230V ac
Number of Outputs:
1
Output Voltage Adjustment Range:
10.5 → 16.1V
Ripple And Noise:
200 (Ripple)mV Pk-Pk
Hazardous Area Certification:
ATEX
Depth:
53mm
Special Features:
Flexible Deployment, Flexible Mounting, Global Use, High Energy Efficiency, Load Monitoring, Low Width, Reliable, Wide Portfolio
Mounting Type:
DIN Rail Mount
Output Current:
4.5A
Series:
LOGO!POWER
Height:
90mm
Output Voltage:
12V dc
Power Rating:
54W
