AC or DC Output Voltage:
dc
Output Current:
6.25A
Series:
DRL
AC or DC Input Voltage:
ac
Input Voltage:
85 → 264V ac
Output Voltage:
12V dc
Power Rating:
75W
Type:
DIN Rail Power Supply
HTSUS:
8504.40.9520
RoHS Status:
ROHS3 Compliant
Power (Watts):
75W
Current - Output (Max):
6.25A
Approval Agency:
CB, CCC, CE, cTUVus, TUV, UKCA
Input Type:
AC or DC
Applications:
ITE (Commercial), Laboratory
Voltage - Output 4:
-
Voltage - Output 5:
-
Voltage - Output 6:
-
Voltage - Output 1:
12V
Voltage - Output 2:
-
Voltage - Output 3:
-
Efficiency:
87.5%
DC Voltage - Input (Max):
375V
Package:
Box
DC Voltage - Input (Min):
120V
Minimum Load Required:
-
Size / Dimension:
4.87" L x 1.06" W x 4.02" H (123.7mm x 26.9mm x 102.1mm)
standardLeadTime:
1 Weeks
Voltage - Isolation:
3 kV
AC Voltage - Input:
85 ~ 264 VAC
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Features:
Adjustable Output, PFC, Universal Input
Series:
DRL (75W)
Operating Temperature:
-20°C ~ 70°C (With Derating)
Standard Number:
60950-1; 61010-1; 62368-1
Number of Outputs:
1
ECCN:
EAR99
