Maximum Diode Capacitance:
4pF
Dimensions:
1.3 x 0.9 x 0.7mm
Mounting Type:
Surface Mount
Power Dissipation:
200mW
Maximum Forward Current:
300mA
Maximum Forward Voltage Drop:
720mV
Height:
0.7mm
Width:
0.9mm
Length:
1.3mm
Package Type:
SOD-523F
Number of Elements per Chip:
1
Minimum Operating Temperature:
-55 °C
Maximum Reverse Voltage:
75V
Maximum Operating Temperature:
+150 °C
Diode Configuration:
Single
Pin Count:
2
HTSUS:
8541.10.0070
Package / Case:
SC-79, SOD-523F
Operating Temperature - Junction:
-55°C ~ 150°C
Speed:
Small Signal =< 200mA (Io), Any Speed
Reverse Recovery Time (trr):
4 ns
Current - Average Rectified (Io):
200mA
Voltage - Forward (Vf) (Max) @ If:
1 V @ 100 mA
Package:
Bulk
Voltage - DC Reverse (Vr) (Max):
75 V
Capacitance @ Vr, F:
4pF @ 0V, 1MHz
Current - Reverse Leakage @ Vr:
5 µA @ 75 V
Mounting Type:
Surface Mount
Series:
-
Supplier Device Package:
SOD-523F
Technology:
Standard
Base Product Number:
1N914B
ECCN:
EAR99
