Depth:
72mm
Series:
PM5000
Approvals:
CE Conforming to IEC 61010-1c, CULus Conforming to UL 61010-1, EN 50470-1, EN 50470-3, IEC 60529, IEC 61557-12, IEC 62053-22, IEC 62053-24
Meter Type:
Electromechanical
Display Type:
LCD
Meter Accuracy:
±0.05 (Frequency) %, ±0.05 (Power Factor) %, ±0.1 (Voltage) %, ±0.15 (Current) °C, ±0.2 (Active Energy) %, ±0.2 (Active Power) %, ±0.5 (Apparent Power) %, ±1 (Reactive Energy) %
Number of Inputs:
4
Number of Phases:
3
Measurement Range:
20 → 400 (Phase and Neutral) V ac, 35 → 690 (Phase) V ac, 45 → 65 Hz, 5 mA → 10A
Number of Outputs:
2
Maximum Measurement:
400 (Phase and Neutral) V ac, 690 (Phase) V ac, 10 A, 65 Hz
Maximum Temperature:
+70°C
Minimum Measurement:
20 (Phase and Neutral) V ac, 35 (Phase) V ac, 5 mA, 45 Hz
Minimum Temperature:
-25°C
Better World Product:
Yes
Communication Port Type:
Modbus
Better World Verification:
Green Premium
Series:
PM5560
Display Type:
Backlit LCD
Number of Phases:
1, 3
