Dimensions:
42.5 x 28 x 37mm
Lead Length:
17mm
Equivalent Series Resistance:
2.8mΩ
Capacitance:
1.2 µF
Tolerance:
±5%
Dielectric Material Family:
Polypropylene (PP)
Maximum Operating Temperature:
+85°C
Dielectric:
PP
Tolerance Plus:
+5%
Lead Diameter:
0.8mm
Length:
42.5mm
Lead Pitch:
6mm
Mounting Type:
Solder Lug
Application:
Clamper, High Frequency, IGBT, Snubber
Series:
C4BS
Capacitor Family:
Film
Depth:
28mm
Height:
37mm
Tolerance Minus:
-5%
Voltage:
1.2 kV ac, 630 V dc
Minimum Operating Temperature:
-40°C
Ratings:
-
Voltage Rating - DC:
1200V (1.2kV)
HTSUS:
8532.25.0030
RoHS Status:
ROHS3 Compliant
ESR (Equivalent Series Resistance):
2.8 mOhms
Capacitance:
1.2 µF
Operating Temperature:
-40°C ~ 85°C
Package / Case:
Rectangular Box
Tolerance:
±5%
Height - Seated (Max):
1.457" (37.00mm)
Dielectric Material:
Polypropylene (PP), Metallized
Voltage Rating - AC:
630V
REACH Status:
REACH Unaffected
Applications:
DC Link, DC Filtering; Snubber
Package:
Bulk
Size / Dimension:
1.673" L x 1.102" W (42.50mm x 28.00mm)
Termination:
Screw Terminals
standardLeadTime:
22 Weeks
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Features:
-
Mounting Type:
Chassis Mount
Series:
C4BS
Lead Spacing:
1.004" (25.50mm)
Base Product Number:
C4BSPB
ECCN:
EAR99
