Eaton - Electronics Division CTX06-14620

CTX06-14620 Eaton - Electronics Division
CTX06-14620
CTX06-14620
Eaton - Electronics Division

Product Information

Ratings:
-
HTSUS:
8504.50.4000
RoHS Status:
RoHS Compliant
Inductance Frequency - Test:
100 kHz
Operating Temperature:
-40°C ~ 75°C
Package / Case:
Nonstandard
Tolerance:
-
Shielding:
Unshielded
DC Resistance (DCR):
16.6mOhm Max
Height - Seated (Max):
0.484" (12.30mm)
Type:
Toroidal
Inductance:
47 µH
Package:
Bulk
Size / Dimension:
0.984" L x 0.984" W (25.00mm x 25.00mm)
Current - Saturation (Isat):
-
Material - Core:
Iron Powder
Current Rating (Amps):
7.1 A
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Frequency - Self Resonant:
-
Mounting Type:
Surface Mount
Series:
CTX
Supplier Device Package:
-
Q @ Freq:
-
ECCN:
EAR99
Checking for live stock

This is manufactured by Eaton - Electronics Division. The manufacturer part number is CTX06-14620. It is assigned with possible HTSUS value of 8504.50.4000. The product is rohs compliant. 100 khz is its inductance frequency value. The product has -40°c ~ 75°c operating temperature range. Moreover, the product comes in [Package/ Case]. Furthermore, the product is shielded with unshielded. It allows DC resistance of 16.6mohm max. It has the maximum seated height of 0.484" (12.30mm) It comes in toroidal configuration. The product has a 47 µh inductance value. It is shipped in bulk. The product's diameters include 0.984" l x 0.984" w (25.00mm x 25.00mm). It is made from durable iron powder. Additionally, the product's output is 7.1 a Its typical moisture sensitivity level is 1 (unlimited). The product is available in surface mount configuration. The product ctx, is a highly preferred choice for users. The product is designated with the ear99 code number

pdf icon
CTX06-14620 01/Sep/2022(PCN Obsolescence/ EOL)
pdf icon
CTX06-14620 Drawing(Datasheets)
pdf icon
Shipping Box and Labels 05/Jan/2018(PCN Packaging)
