This is manufactured by Molex. The manufacturer part number is 2086592840. The product igrid 2.0, is a highly preferred choice for users. It comes in 2 of rows. Moreover, the product is 2mm The product contains 28 contacts. It has nice contact finishing of gold. Additionally, the product is designed with board to cable/wire Style. It has possible tin contact post finishing. It is assigned with possible HTSUS value of 8536.69.4040. The product is rohs3 compliant. The product has -40°c ~ 105°c operating temperature range. Additionally, it features 39.4µin (1.00µm) of post thickness. The product carries possible position value of 28. 0.327" (8.30mm) of insulation height. Moreover, the product has a nominal 250vac/dc voltage rating. Furthermore, a bespoke product features shrouded - 4 wall. It carries ul94 v-0 of material flammability rating. In addition, beige is the insulation color of the product. It has a typical square shape. It has a robust polyamide (pa), nylon, glass filled insulation material. It is shipped in tray. It carries 0.079" (2.00mm) of row spacing. plug Connector type offer robust functionality. However, all is the Number of Positions Loaded. Its typical moisture sensitivity level is 1 (unlimited). However, 3.94µin (0.100µm) is the "Contact Finish Thickness - Mating" of the product. Furthermore, latch lock is the Fastening Type of the product. The product features solder termination style. It has a long 46 weeks standard lead time. Additionally, the product's output is varies by wire gauge 0.126" (3.20mm) is the given possible contact length (post) values. It has 0.079" (2.00mm) of pitch-mating value. The product is available in through hole, right angle configuration. The product igrid 208659, is a highly preferred choice for users. It has typical contact type of male pin. The product is made from sturdy brass materials. Moreover, it corresponds to 208659, a base product number of the product. The product is designated with the ear99 code number
For more information please check the datasheets.
