This is manufactured by Standex-Meder Electronics. The manufacturer part number is HF12-1A54-8. It is assigned with possible HTSUS value of 8536.41.0030. The coil voltage of the product is 12vdc. Moreover, it has pc pin terminal style. The product has -40°c ~ 85°c operating temperature range. It holds up to 250 ohms coil resistance. It has a coil current of 47.9 ma. The coil is a non latching type. The product's switching voltage is 500vac, 500vdc - max. Robust coil power of 575mw. In addition, it is reach unaffected. On the other hand, 8.4 vdc is the given crucial/must operating voltage. It is shipped in bulk. It also has a spst-no (1 form a) contact form. Its typical moisture sensitivity level is 1 (unlimited). The operating time of the product is 3 ms. While the must release voltage is a 1.8 vdc. It has a contact current rating of 1.5 a. The product is available in through hole configuration. The product hf, is a highly preferred choice for users. While 1 ms is its release time. The product is designated with the ear99 code number
For more information please check the datasheets.
