Base Product Number:
CS5
HTSUS:
8504.40.6007
RoHS Status:
RoHS Compliant
Power (Watts):
120W
Current - Output (Max):
5A
Approval Agency:
ABS, CSA, DNV GL, EAC, IEC, UL
Input Type:
AC
Applications:
ITE (Commercial)
Voltage - Output 4:
-
Voltage - Output 5:
-
Voltage - Output 6:
-
Voltage - Output 1:
24V
Voltage - Output 2:
-
Voltage - Output 3:
-
Efficiency:
90.2%
DC Voltage - Input (Max):
300V
Package:
Box
DC Voltage - Input (Min):
264V
Minimum Load Required:
-
Size / Dimension:
4.61" L x 1.26" W x 4.88" H (117.0mm x 32.0mm x 124.0mm)
Voltage - Isolation:
500 V
AC Voltage - Input:
180 ~ 264 VAC, 264 ~ 300 VAC
Moisture Sensitivity Level (MSL):
Not Applicable
Features:
Adjustable Output, Load Sharing
Series:
DIMENSION C (120W)
Operating Temperature:
-25°C ~ 70°C (With Derating)
Standard Number:
Class I Div 2; 508; 60950-1; 61010-2-201
Number of Outputs:
1
ECCN:
EAR99
