Maximum Temperature:
+70°C
AC or DC Output Voltage:
dc
Minimum Temperature:
-25°C
AC or DC Input Voltage:
ac
Width:
37mm
MTBF:
>868000h
Electrical Phase:
1
Type:
Switch Mode
Standards Met:
CB Scheme, DIN VDE 0100-410, EN 50178/VDE 0160 (PELV), EN 60204-1, EN 60715, EN 60950-1 (SELV) and EN 60204 (PELV), EN 60950-1/VDE 0805 (SELV), EN 61000-3-2, EN 61000-4-11, EN 61000-6-2:2005, EN 61558-2-16, UL Listed UL 508, UL/C-UL Recognized UL 60950
Input Voltage:
85 → 264V ac
Number of Outputs:
1
Output Voltage Adjustment Range:
±1%
Ripple And Noise:
<40mV Pk-Pk
Depth:
125mm
Special Features:
Idle and Short Circuit Proof
Mounting Type:
DIN Rail Mount
Output Current:
6.25A
Series:
UNO-PS/1AC/24DC/150W
Height:
130mm
Output Voltage:
24V dc
Power Rating:
150W
HTSUS:
8504.40.6018
RoHS Status:
RoHS Compliant
Power (Watts):
150W
Current - Output (Max):
6.25A
Approval Agency:
CB, cULus, cURus
Input Type:
AC
Applications:
ITE (Commercial)
Voltage - Output 4:
-
Voltage - Output 5:
-
Voltage - Output 6:
-
Voltage - Output 1:
24V
Voltage - Output 2:
-
Voltage - Output 3:
-
Efficiency:
94%
Package:
Bulk
Minimum Load Required:
-
Size / Dimension:
4.92" L x 1.46" W x 5.12" H (125.0mm x 37.0mm x 130.0mm)
Voltage - Isolation:
3 kV
AC Voltage - Input:
85 ~ 264 VAC
Moisture Sensitivity Level (MSL):
Not Applicable
Features:
IP20, Load Sharing, Universal Input
Series:
UNO
Operating Temperature:
-25°C ~ 70°C (With Derating)
Number of Outputs:
1
ECCN:
EAR99
