Number of Outputs:
2
Maximum Temperature:
+70°C
AC or DC Output Voltage:
dc
Standards Met:
cUL, cUL Recognised, cULus Recognised, EAC, UL, UL Recognised
Mounting Type:
DIN Rail Mount
Efficiency:
93.3%
Series:
TRIO-PS-2G/3AC/24DC/40
Special Features:
Dynamic Boost, Ensure Reliable Supply of All Loads, Optimally Tailored to the Stringent Requirements, Perfected For Use in Machine Building, Performs Under Challenging Ambient Conditions, Robust Electrical & Mechanical Design, Tool-Free Fast Connection Technology for Solid and Stranded Conductors with Ferrule
AC or DC Input Voltage:
ac
Height:
130mm
Width:
160mm
Depth:
160mm
MTBF:
>1051000 h @ 40 °C, >1730000 h @ 25 °C, >512000 h @ 60°C
Output Voltage:
24V dc
Minimum Temperature:
-25°C
Power Rating:
960W
Type:
Switch Mode
Output Current:
40A
HTSUS:
8504.40.9540
RoHS Status:
RoHS Compliant
Power (Watts):
960W
Current - Output (Max):
40A
Approval Agency:
cUL, UL
Input Type:
AC
Applications:
Industrial, ITE (Commercial)
Voltage - Output 4:
-
Voltage - Output 5:
-
Voltage - Output 6:
-
Voltage - Output 1:
24V
Voltage - Output 2:
-
Voltage - Output 3:
-
Efficiency:
93.3%
Package:
Box
Minimum Load Required:
-
Size / Dimension:
6.30" L x 4.33" W x 5.12" H (160.0mm x 110.0mm x 130.0mm)
Voltage - Isolation:
3 kV
AC Voltage - Input:
400 ~ 500 VAC (3 Phase)
Moisture Sensitivity Level (MSL):
Not Applicable
Features:
Adjustable Output, IP20, Universal Input
Series:
TRIO
Operating Temperature:
-25°C ~ 70°C (With Derating)
Number of Outputs:
1
ECCN:
EAR99
