Maximum Temperature:
+65°C
AC or DC Output Voltage:
dc
Minimum Temperature:
-25°C
AC or DC Input Voltage:
ac, dc
Width:
60mm
MTBF:
290000 (Minimum)h
Electrical Phase:
1
Type:
Power Supply
Load Regulation:
1%
Standards Met:
ANSI/ISA, CE:TUV, CSA C22.2 No 107.1.213.223, cULus, EN 50178, EN 60950-1, EN 61204-3, UL 310, UL 508
Efficiency:
90%
Input Voltage:
85 → 264V ac
Number of Outputs:
1
Output Voltage Adjustment Range:
±10%
Ripple And Noise:
4% Pk-Pk
Depth:
125mm
Special Features:
Can be Installed in 6 Directions, Compact Size Preserves Panel Space, Five-Year Factory Warranty
Mounting Type:
DIN Rail Mount
Output Current:
10A
Series:
PS5R
Height:
125mm
Output Voltage:
24V dc
Power Rating:
240W
HTSUS:
8504.40.9530
RoHS Status:
ROHS3 Compliant
Power (Watts):
240W
Current - Output (Max):
10A
Approval Agency:
CE, cULus, TUV
Input Type:
AC or DC
Applications:
Hazardous Locations, Industrial, ITE (Commercial)
Voltage - Output 4:
-
Voltage - Output 5:
-
Voltage - Output 6:
-
Voltage - Output 1:
24V
Voltage - Output 2:
-
Voltage - Output 3:
-
Efficiency:
90%
DC Voltage - Input (Max):
370V
Package:
Bulk
DC Voltage - Input (Min):
100V
Minimum Load Required:
-
Size / Dimension:
4.92" L x 2.36" W x 4.92" H (125.0mm x 60.0mm x 125.0mm)
standardLeadTime:
26 Weeks
Voltage - Isolation:
3 kV
AC Voltage - Input:
85 ~ 264 VAC
Moisture Sensitivity Level (MSL):
Not Applicable
Features:
Adjustable Output, IP20, Universal Input
Series:
PS5R-V (240W)
Operating Temperature:
-25°C ~ 65°C (With Derating)
Standard Number:
62368-1
Number of Outputs:
1
ECCN:
EAR99
