Maximum Temperature:
+65°C
Minimum Temperature:
-25°C
Regulator Type:
Switched Mode Power Supply
Application:
Harsh Environment, Industrial, Remote Site, Telecom
MTBF:
800000h
Protection Features:
Over Current Protection
Holdup Time:
>10ms
Load Regulation:
≤0.5%
Standards Met:
CE, CRUus, CULus
Output Current:
5A
Number of Outputs:
1
Line Regulation:
≤0.5%
Ripple And Noise:
≤1 (Ripple) %, ≤2 (Noise) %
Length:
120mm
Special Features:
DIN Rail or Chassis Mount by Removing DIN Clips, Five Year Limited Warranty, Galvanic Isolation, IP20 Protection, Rugged Encapsulated Design to Resist Environment
Power Signal Conversion Type:
DC-DC
Weight:
390g
Mounting Type:
Chassis Mount, DIN Rail Mount
Width:
65mm
Series:
SCD
Input Voltage Range:
20 → 72 V dc
Depth:
33mm
Output Voltage:
5V dc
Power Rating:
30W
HTSUS:
8504.40.9580
RoHS Status:
RoHS Compliant
Power (Watts):
25W
Current - Output (Max):
5A
Approval Agency:
CE, cULus, cURus
Input Type:
DC
Applications:
Industrial, ITE (Commercial)
Voltage - Output 4:
-
Voltage - Output 5:
-
Voltage - Output 6:
-
Voltage - Output 1:
5V
Voltage - Output 2:
-
Voltage - Output 3:
-
Efficiency:
-
DC Voltage - Input (Max):
72V
Package:
Bulk
DC Voltage - Input (Min):
20V
Minimum Load Required:
No
Size / Dimension:
2.55" L x 1.29" W x 4.51" H (64.8mm x 32.8mm x 115.0mm)
standardLeadTime:
12 Weeks
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Features:
IP20
Series:
SCD
Operating Temperature:
-25°C ~ 65°C
Base Product Number:
SCD30S5
Number of Outputs:
1
ECCN:
EAR99
