Maximum Temperature:
+65°C
AC or DC Output Voltage:
Dc
Minimum Temperature:
-25°C
AC or DC Input Voltage:
Ac
Application:
Industrial
MTBF:
800000h
Maximum Output Voltage:
12V dc
Protection Features:
Over Voltage Protection, Short Circuit Protection
Holdup Time:
>50ms
Standards Met:
Class II, CUL, EN 50082-2, EN 55011 Class B, EN 55022 Class B, EN 60950, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, UL 1950, VDE 0805
Input Frequency Range:
50/60Hz
Efficiency:
≥68%
Input Voltage:
230V ac
Number of Outputs:
3
Line Regulation:
≤0.5%
Ripple And Noise:
≤1 (Ripple) %, ≤2 (Noise) %
Minimum Output Voltage:
5V dc
Power Signal Conversion Type:
AC-DC
Mounting Type:
DIN Rail
Output Current:
3 A, 600 mA
Series:
SCP
Weight:
340 g, 380 g
Output Voltage:
5 V dc
Power Rating:
30W
Maximum Input Voltage:
264V ac
Minimum Input Voltage:
85V ac
HTSUS:
8504.40.9510
RoHS Status:
RoHS Compliant
Power (Watts):
29W
Current - Output (Max):
3A, 600mA, 600mA
Approval Agency:
CE, cURus
Input Type:
AC or DC
Applications:
ITE (Commercial)
Voltage - Output 4:
-
Voltage - Output 5:
-
Voltage - Output 6:
-
Voltage - Output 1:
5V
Voltage - Output 2:
-12V
Voltage - Output 3:
12V
Efficiency:
68%
DC Voltage - Input (Max):
375V
Package:
Bulk
DC Voltage - Input (Min):
100V
Minimum Load Required:
Yes
Size / Dimension:
2.55" L x 1.29" W x 4.71" H (65.0mm x 33.0mm x 120.0mm)
standardLeadTime:
12 Weeks
AC Voltage - Input:
85 ~ 264 VAC
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Features:
IP20, Universal Input
Series:
SCP (30W)
Operating Temperature:
-25°C ~ 65°C
Base Product Number:
SCP30
Number of Outputs:
3
ECCN:
EAR99
