Maximum Temperature:
+60°C
AC or DC Output Voltage:
Dc
Minimum Temperature:
-10°C
AC or DC Input Voltage:
Ac
Application:
Industrial
MTBF:
>500000h
Maximum Output Voltage:
28.5V dc
Protection Features:
Over Voltage Protection, Short Circuit Protection
Maximum Input Current:
250 mA, 400 mA
Holdup Time:
>25ms
Standards Met:
CE, CRUus, CULus, RoHS Compliant
Input Frequency Range:
47 → 63Hz
Efficiency:
>80%
Input Voltage:
230V ac
Number of Outputs:
1
Ripple And Noise:
<50mV Pk-Pk
Minimum Output Voltage:
22.5V dc
Special Features:
Continuous Short Circuit Protection, Low Output Noise
Power Signal Conversion Type:
AC-DC
Mounting Type:
DIN Rail
Output Current:
600 mA
Series:
SDP
Weight:
180g
Output Voltage:
24 V dc
Power Rating:
15W
Maximum Input Voltage:
264V ac
Minimum Input Voltage:
85V ac
HTSUS:
8504.40.9510
RoHS Status:
RoHS Compliant
Power (Watts):
15W
Current - Output (Max):
630mA
Approval Agency:
CE, cULus, cURus
Input Type:
AC or DC
Applications:
Hazardous Locations, Industrial, ITE (Commercial)
Voltage - Output 4:
-
Voltage - Output 5:
-
Voltage - Output 6:
-
Voltage - Output 1:
24V
Voltage - Output 2:
-
Voltage - Output 3:
-
Efficiency:
80%
DC Voltage - Input (Max):
375V
Package:
Bulk
DC Voltage - Input (Min):
90V
Minimum Load Required:
-
Size / Dimension:
3.58" L x 0.90" W x 2.95" H (90.9mm x 22.9mm x 74.9mm)
standardLeadTime:
12 Weeks
AC Voltage - Input:
85 ~ 264 VAC
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Features:
Adjustable Output, IP20, Universal Input
Series:
SDP
Operating Temperature:
-10°C ~ 70°C (With Derating)
Base Product Number:
SDP06
Number of Outputs:
1
ECCN:
EAR99
