Number of Outputs:
1
Ripple And Noise:
<50mV Pk-Pk
Output Current:
2.75A
Standards Met:
CE, cRUus, cULus, RoHS Compliant
Mounting Type:
DIN Rail Mount
Maximum Temperature:
+60°C
Series:
SDP
Electrical Phase:
1
Special Features:
Continuous Short Circuit Protection, Low Output Noise
AC or DC Input Voltage:
ac, dc
Height:
75mm
Width:
75mm
Depth:
91mm
MTBF:
>500000h
Output Voltage:
12V dc
Minimum Temperature:
-10°C
AC or DC Output Voltage:
dc
Power Rating:
33W
Input Voltage:
85 → 264V ac
HTSUS:
8504.40.9510
RoHS Status:
RoHS Compliant
Power (Watts):
30W
Current - Output (Max):
2.5A
Approval Agency:
CE, cULus, cURus
Input Type:
AC or DC
Applications:
Hazardous Locations, Industrial, ITE (Commercial)
Voltage - Output 4:
-
Voltage - Output 5:
-
Voltage - Output 6:
-
Voltage - Output 1:
12V
Voltage - Output 2:
-
Voltage - Output 3:
-
Efficiency:
80%
DC Voltage - Input (Max):
375V
Package:
Bulk
DC Voltage - Input (Min):
90V
Minimum Load Required:
-
Size / Dimension:
3.58" L x 1.77" W x 2.95" H (90.9mm x 45.0mm x 74.9mm)
standardLeadTime:
12 Weeks
AC Voltage - Input:
85 ~ 264 VAC
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Features:
Adjustable Output, IP20, Universal Input
Series:
SDP
Operating Temperature:
-10°C ~ 70°C (With Derating)
Base Product Number:
SDP2
Number of Outputs:
1
ECCN:
EAR99
