Function:
Motor Control
Priced to Clear:
Yes
Current Rating:
27.1 A @ 200 V ac
Standards Met:
ATEX, CE, CSA, CUL, EAC, EN 954-1, EN ISO 13849-1, EN ISO 13849-2, IEC 60204-1, IEC 6100, IEC 61158, IEC 61508, IEC 61784, IEC/EN 60721, TUV, UL 508C
Mounting Type:
Wall Mount
IP Rating:
IP21
Series:
ATV63
Drive Type:
Adjustable Frequency
Special Features:
Embedded Power Measurement & Energy Dashboard, Energy Saving, Fluids Management Processing, Services Oriented Drive
Filter Included:
Yes
Ambient Temperature:
-15 → +50 (without Derating) °C, Maximum of +60 (with Derating) °C
Control Panel:
Yes
For Use With:
Three Phase Asynchronous & Synchronous Motors
Supply Voltage:
230 V ac
Overall Length:
211mm
Phase:
3
Overall Depth:
545.9mm
Power Rating:
7.5 kW
Field Bus Communication Type:
Profibus
Overall Width:
232mm
Output Frequency:
0.1 → 500Hz
