STO:
Yes
Phase:
1
Series:
Altivar
Function:
Motor Control
IP Rating:
IP20
Drive Type:
Variable Frequency
For Use With:
Asynchronous Motors, Synchronous Motors
Power Rating:
0.55 kW
Control Panel:
Yes
Mounting Type:
DIN Rail
Overall Depth:
143mm
Overall Width:
138mm
Standards Met:
CE, CSA, cUL, EAC, EN 954-1, EN ISO 13849-1, EN ISO 13849-2, IEC 60204-1, IEC 6100, IEC 61158, IEC 61508, IEC 61784, IEC/EN 60721, NOM 117, RCM, UL
Current Rating:
7.9 A
Overall Length:
72mm
Supply Voltage:
230 V ac
Filter Included:
Yes
Output Frequency:
0.1 → 599Hz
Special Features:
Enhanced Automation Capabilities, Even at Low Speed & Dynamic Accuracy for Start/Stop Application, Open-Loop Motor Control Combined, Variable Speed Drive Improves Machine Effectiveness
Better World Claim:
Saves energy
Better World Product:
Yes
Better World Verification:
Green Premium
Field Bus Communication Type:
Profibus
