Function:
Motor Control
Current Rating:
46 A
Standards Met:
CE, CUL, EAC, RCM, UkrSEPRO, UL
Mounting Type:
Flange Mount
IP Rating:
IP20
Series:
DC1
Drive Type:
Vector Control
Special Features:
Control of High Efficient IE4 Motors, DC Braking, Detachable Control Signal Terminal Strip, Fast Commissioning with 14 Basic Parameters, Full Short Circuit Protection, Integrated Braking Transistor, Integrated Canopen & Modbus RTU, Integrated EMC Filter, Integrated PI Controller, Large Overload Capability, Sensorless Vector Control, V/F Control, Voltage Boost
Filter Included:
Yes
Ambient Temperature:
+50°C
For Use With:
Conveyor Belt Systems, Fan Application, Pump
Supply Voltage:
400 V ac
Overall Length:
173mm
Phase:
3
Overall Depth:
418.5mm
Power Rating:
22 kW
Field Bus Communication Type:
CANOpen
Overall Width:
211mm
