Maximum Low Level Output Current:
24mA
Dimensions:
5.1 x 4.5 x 1.05mm
Mounting Type:
Surface Mount
Number of Inputs per Gate:
2
Minimum Operating Supply Voltage:
2 V
Logic Function:
AND
Logic Family:
AC
Height:
1.05mm
Width:
4.5mm
Length:
5.1mm
Package Type:
TSSOP
Propagation Delay Test Condition:
50pF
Minimum Operating Temperature:
-40 °C
Maximum Propagation Delay Time @ Maximum CL:
10 ns @ 50 pF
Maximum Operating Supply Voltage:
6 V
Number of Elements:
4
Maximum Operating Temperature:
+85 °C
Pin Count:
14
Maximum High Level Output Current:
-24mA
Number of Inputs:
2
HTSUS:
8542.39.0001
RoHS Status:
ROHS3 Compliant
Current - Quiescent (Max):
2 µA
Operating Temperature:
-40°C ~ 85°C
Package / Case:
14-TSSOP (0.173", 4.40mm Width)
Input Logic Level - Low:
0.9V ~ 1.65V
Input Logic Level - High:
2.1V ~ 3.85V
REACH Status:
REACH Unaffected
Max Propagation Delay @ V, Max CL:
7.5ns @ 5V, 50pF
Package:
Tape & Reel (TR)
Moisture Sensitivity Level (MSL):
1 (Unlimited)
standardLeadTime:
28 Weeks
Number of Circuits:
4
Features:
-
Mounting Type:
Surface Mount
Series:
74AC
Logic Type:
AND Gate
Supplier Device Package:
14-TSSOP
Voltage - Supply:
2V ~ 6V
Current - Output High, Low:
24mA, 24mA
Base Product Number:
74AC08
ECCN:
EAR99
