Dimensions:
6.6 x 4.5 x 1.05mm
Number of I2C Channels:
2
Number of USART Channels:
2
USB Channels:
1
Width:
4.5mm
Program Memory Size:
32 kB
Number of PWM Units:
1 x 16 bit
RAM Size:
6 kB
Data Bus Width:
32bit
Instruction Set Architecture:
RISC
Program Memory Type:
Flash
Package Type:
TSSOP
Maximum Frequency:
48MHz
Number of PCI Channels:
0
Number of LIN Channels:
0
Maximum Operating Temperature:
+85 °C
Number of UART Channels:
0
Minimum Operating Temperature:
-40 °C
Maximum Number of Ethernet Channels:
0
Family Name:
STM32F0
Device Core:
ARM Cortex M0
Length:
6.6mm
Number of ADC Units:
1
Pin Count:
20
Pulse Width Modulation:
1 (6 x 16 bit)
Mounting Type:
Surface Mount
Number of Ethernet Channels:
0
Height:
1.05mm
Typical Operating Supply Voltage:
2 → 3.6 V
ADCs:
10 x 12 bit
Number of CAN Channels:
1
Number of SPI Channels:
1
HTSUS:
8542.31.0001
RoHS Status:
ROHS3 Compliant
Program Memory Size:
32KB (32K x 8)
Peripherals:
DMA, I²S, POR, PWM, WDT
Operating Temperature:
-40°C ~ 85°C (TA)
Voltage - Supply (Vcc/Vdd):
1.65V ~ 3.6V
Package / Case:
20-TSSOP (0.173", 4.40mm Width)
RAM Size:
6K x 8
Program Memory Type:
FLASH
REACH Status:
REACH Unaffected
Connectivity:
CANbus, HDMI-CEC, I²C, IrDA, LINbus, SPI, UART/USART, USB
Package:
Tube
EEPROM Size:
-
Oscillator Type:
Internal
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Number of I/O:
16
standardLeadTime:
16 Weeks
Core Size:
32-Bit Single-Core
Mounting Type:
Surface Mount
Series:
STM32F0
Supplier Device Package:
20-TSSOP
Data Converters:
A/D 12x12b
Core Processor:
ARM® Cortex®-M0
Speed:
48MHz
Base Product Number:
STM32F042
ECCN:
3A991A2
