Dimensions:
14.2 x 14.2 x 1.45mm
Number of I2C Channels:
2
Number of USART Channels:
3
USB Channels:
1
Width:
14.2mm
Program Memory Size:
128 kB
Number of PWM Units:
4
RAM Size:
32 kB
Data Bus Width:
32bit
Instruction Set Architecture:
RISC
Program Memory Type:
Flash
Package Type:
LQFP
Maximum Frequency:
32MHz
Number of PCI Channels:
0
Number of LIN Channels:
0
Maximum Operating Temperature:
+85 °C
Number of UART Channels:
0
Minimum Operating Temperature:
-40 °C
Maximum Number of Ethernet Channels:
0
Family Name:
STM32L1
Device Core:
ARM Cortex M3
Length:
14.2mm
Number of ADC Units:
1
Pin Count:
100
Pulse Width Modulation:
4
Mounting Type:
Surface Mount
Number of Ethernet Channels:
0
Height:
1.45mm
Typical Operating Supply Voltage:
1.65 → 3.6 V
ADCs:
24 x 12 bit
Number of CAN Channels:
0
Number of SPI Channels:
2
HTSUS:
8542.31.0001
RoHS Status:
ROHS3 Compliant
Program Memory Size:
128KB (128K x 8)
Peripherals:
Brown-out Detect/Reset, Cap Sense, DMA, I²S, LCD, POR, PWM, WDT
Operating Temperature:
-40°C ~ 85°C (TA)
Voltage - Supply (Vcc/Vdd):
1.8V ~ 3.6V
Package / Case:
100-LQFP
RAM Size:
32K x 8
Program Memory Type:
FLASH
REACH Status:
REACH Unaffected
Connectivity:
I²C, IrDA, LINbus, SPI, UART/USART, USB
Package:
Tray
EEPROM Size:
4K x 8
Oscillator Type:
Internal
Moisture Sensitivity Level (MSL):
3 (168 Hours)
Number of I/O:
83
Core Size:
32-Bit Single-Core
Mounting Type:
Surface Mount
Series:
STM32L1
Supplier Device Package:
100-LQFP (14x14)
Data Converters:
A/D 24x12b; D/A 2x12b
Core Processor:
ARM® Cortex®-M3
Speed:
32MHz
Base Product Number:
STM32L152
ECCN:
3A991A2
