Microchip ATMEGA1284-PU, 8bit AVR Microcontroller, 20MHz, 128 kB Flash, 44-Pin PDIP

ATMEGA1284-PU Microchip , 8bit AVR Microcontroller, 20MHz, 128 kB Flash, 44-Pin PDIP
ATMEGA1284-PU
ATMEGA1284-PU Microchip , 8bit AVR Microcontroller, 20MHz, 128 kB Flash, 44-Pin PDIP
Microchip

Product Information

Dimensions:
52.57 x 13.97 x 4.44mm
USB Channels:
0
Width:
13.97mm
Program Memory Size:
128 kB
Number of PWM Units:
1
RAM Size:
16 kB
Data Bus Width:
8bit
Instruction Set Architecture:
RISC
Program Memory Type:
Flash
Package Type:
PDIP
Maximum Frequency:
20MHz
Maximum Operating Temperature:
+85 °C
Maximum Number of Ethernet Channels:
0
Family Name:
ATmega
Device Core:
AVR
Length:
52.57mm
Number of ADC Units:
1
Pin Count:
40
Pulse Width Modulation:
1 (8 Channel)
Mounting Type:
Surface Mount
Height:
4.44mm
Typical Operating Supply Voltage:
1.8 → 5.5 V
ADCs:
8 x 10 bit
Minimum Operating Temperature:
-40 °C
RoHs Compliant
Checking for live stock

This is 8bit AVR Microcontroller 20MHz 128 kB Flash 44-Pin PDIP manufactured by Microchip. The manufacturer part number is ATMEGA1284-PU. The given dimensions of the product include 52.57 x 13.97 x 4.44mm. Furthermore, the product is 13.97mm wide. In addition, 128 kb is the program memory size. The product has typical 16 kb RAM size. It is a flash program memory type. It has a maximum operating temperature of +85 °c. Its accurate length is 52.57mm. The product is available in surface mount configuration. In addition, the height is 4.44mm. Whereas, the minimum operating temperature of the product is -40 °c.
