Maximum Low Level Output Current:
8mA
Maximum High Level Output Current:
-8mA
Dimensions:
10 x 4 x 1.5mm
Mounting Type:
Surface Mount
Maximum Propagation Delay Time @ Maximum CL:
29.5 ns @ 50 pF
Minimum Operating Supply Voltage:
2 V
Maximum Quiescent Current:
40µA
Logic Function:
Monostable Multivibrator
Logic Family:
VHC
Height:
1.5mm
Width:
4mm
Length:
10mm
Package Type:
SOIC
Number of Elements per Chip:
8
Minimum Operating Temperature:
-40 °C
Minimum Pulse Width:
5 ns
Maximum Operating Supply Voltage:
5.5 V
Maximum Operating Temperature:
+85 °C
Pin Count:
16
Propagation Delay Test Condition:
50pF
HTSUS:
8542.39.0001
RoHS Status:
ROHS3 Compliant
Propagation Delay:
8.1 ns
Operating Temperature:
-40°C ~ 85°C
Package / Case:
16-SOIC (0.154", 3.90mm Width)
REACH Status:
REACH Unaffected
Independent Circuits:
2
Package:
Tube
Moisture Sensitivity Level (MSL):
1 (Unlimited)
standardLeadTime:
29 Weeks
Mounting Type:
Surface Mount
Series:
74VHC
Logic Type:
Monostable
Supplier Device Package:
16-SOIC
Voltage - Supply:
2 V ~ 5.5 V
Current - Output High, Low:
8mA, 8mA
Schmitt Trigger Input:
Yes
Base Product Number:
74VHC123
ECCN:
EAR99
