Dimensions:
167 x 84 x 45mm
Capacitance Measurement Resolution:
0.01nF
DC Current Measurement Resolution:
0.1mA
Absolute Maximum DC Voltage Measurement:
600V dc
Width:
84mm
AC Current Measurement Resolution:
0.1mA
Best Temperature Measurement Accuracy:
0.8 %
True RMS:
No
Absolute Maximum AC Voltage Measurement:
600V ac
Model Number p:
760-1
Resistance Measurement Resolution:
100mΩ
Best AC Voltage Accuracy:
0.8 %
Absolute Maximum AC Current Measurement:
10A ac
Maximum Frequency:
500kHz
Absolute Maximum Capacitance Measurement:
100µF
Battery Type:
AAA
Absolute Maximum Resistance Measurement:
40MΩ
Maximum Operating Temperature:
+50°C
Best Capacitance Measurement Accuracy:
0.8 %
Minimum Operating Temperature:
-10°C
Safety Category Level:
CAT III, CAT IV
Length:
167mm
Absolute Maximum Temperature Measurement:
+500°C
Absolute Maximum DC Current Measurement:
10A dc
Display Type:
Digital
Best DC Current Accuracy:
0.8 %
Weight:
340g
AC Voltage Measurement Resolution:
0.1mV
Best AC Current Accuracy:
0.8 %
Safety Category Voltage:
300 V, 600 V
Multimeter Type:
Handheld
Height:
45mm
Best Resistance Measurement Accuracy:
0.8 %
Best DC Voltage Accuracy:
0.8 %
DC Voltage Measurement Resolution:
0.1mV
Functions Measured:
AC Current, AC Voltage, Capacitance, DC Current, DC Voltage, Frequency, Resistance
