Width:
84mm
Height:
45mm
Length:
167mm
Weight:
268g
True RMS:
Yes
Dimensions:
167 x 84 x 45mm
Battery Type:
AAA
Display Type:
Digital
Model Number p:
760-3
Multimeter Type:
Handheld
Maximum Frequency:
60MHz
Functions Measured:
AC Current, AC Voltage, Capacitance, DC Current, DC Voltage, Frequency, Resistance, Temperature
Safety Category Level:
CAT III, CAT IV
Safety Category Voltage:
600 V, 1000 V
Best AC Current Accuracy:
± (1.5 % of mv + 5 Digit)
Best AC Voltage Accuracy:
± (1.0 % of mv + 3 Digit)
Best DC Current Accuracy:
± (1.5 % of mv + 5 Digit)
Best DC Voltage Accuracy:
± (0.8 % of mv +3 Digit)
Maximum Operating Temperature:
+50°C
Minimum Operating Temperature:
-10°C
AC Current Measurement Resolution:
0.1µA
AC Voltage Measurement Resolution:
0.1mV
DC Current Measurement Resolution:
100mA
DC Voltage Measurement Resolution:
0.1mV
Resistance Measurement Resolution:
10mΩ
Capacitance Measurement Resolution:
0.01nF
Temperature Measurement Resolution:
0.2°C
Best Resistance Measurement Accuracy:
0.1 %
Best Capacitance Measurement Accuracy:
0.1 %
Best Temperature Measurement Accuracy:
0.1 %
Absolute Maximum AC Current Measurement:
10A ac
Absolute Maximum AC Voltage Measurement:
1000V ac
Absolute Maximum DC Current Measurement:
10A dc
Absolute Maximum DC Voltage Measurement:
1000V dc
Absolute Maximum Resistance Measurement:
60MΩ
Absolute Maximum Capacitance Measurement:
60mF
Absolute Maximum Temperature Measurement:
+500°C
