Dimensions:
55 x 86 x 169mm
Capacitance Measurement Resolution:
1nF
DC Current Measurement Resolution:
0.01µA dc
Temperature Measurement Resolution:
0.1°C
Absolute Maximum DC Voltage Measurement:
600V dc
Width:
86mm
Battery Life:
500 h
AC Current Measurement Resolution:
0.01µA ac
Best Temperature Measurement Accuracy:
±1% + 1 °C
True RMS:
Yes
Absolute Maximum AC Voltage Measurement:
600V ac
Model Number p:
U1232A
Resistance Measurement Resolution:
100mΩ
Best AC Voltage Accuracy:
±4% + 3 Digits
Absolute Maximum AC Current Measurement:
10A ac
Maximum Frequency:
1kHz
Absolute Maximum Capacitance Measurement:
10mF
Battery Type:
AAA x 4
Absolute Maximum Resistance Measurement:
60MΩ
Maximum Operating Temperature:
+55°C
Best Capacitance Measurement Accuracy:
±1.9% + 2 Digits
Minimum Operating Temperature:
-10°C
Safety Category Level:
CAT III
Length:
55mm
Absolute Maximum Temperature Measurement:
+1372°C
Absolute Maximum DC Current Measurement:
10A dc
Display Type:
Digital
Best DC Current Accuracy:
±1% + 3 Digits
Weight:
365g
AC Voltage Measurement Resolution:
0.1mV ac
Best AC Current Accuracy:
±1.5% + 3 Digits
Safety Category Voltage:
600V
Multimeter Type:
Handheld
Height:
169mm
Best Resistance Measurement Accuracy:
±1.5% + 3 Digits
Best DC Voltage Accuracy:
±0.5% + 2 Digits
DC Voltage Measurement Resolution:
0.1mV dc
Functions Measured:
AC Current, AC Voltage, Capacitance, Continuity, DC Current, DC Voltage, Diode, Frequency, Resistance, Temperature
