Dimensions:
167 x 84 x 46mm
Capacitance Measurement Resolution:
1nF
DC Current Measurement Resolution:
0.001A
Absolute Maximum DC Voltage Measurement:
600V dc
Width:
84mm
Battery Life:
400 h
AC Current Measurement Resolution:
0.001A
True RMS:
Yes
Absolute Maximum AC Voltage Measurement:
600V ac
Model Number p:
117
Resistance Measurement Resolution:
100mΩ
Best AC Voltage Accuracy:
±1% + 3 Digits
Absolute Maximum AC Current Measurement:
10A ac
Maximum Frequency:
50kHz
Absolute Maximum Capacitance Measurement:
9.999F
Battery Type:
9V
Absolute Maximum Resistance Measurement:
40MΩ
Maximum Operating Temperature:
+50°C
Best Capacitance Measurement Accuracy:
±1.9% + 2 Digits
Minimum Operating Temperature:
-10°C
Safety Category Level:
CAT III
Length:
167mm
Absolute Maximum DC Current Measurement:
10A dc
Display Type:
LCD
Best DC Current Accuracy:
±1% + 3 Digits
Weight:
550g
AC Voltage Measurement Resolution:
0.1mV ac
Best AC Current Accuracy:
±1.5% + 3 Digits
Safety Category Voltage:
600V
Multimeter Type:
Handheld
Height:
46mm
Best Resistance Measurement Accuracy:
±1.5% + 2 Digits
Best DC Voltage Accuracy:
±0.5% + 2 Digits
DC Voltage Measurement Resolution:
0.1mV dc
Functions Measured:
AC Current, AC Voltage, Capacitance, Continuity, DC Current, DC Voltage, Diode, Frequency, Resistance
