Dimensions:
198.1 x 100 x 63.5mm
Capacitance Measurement Resolution:
10pF
DC Current Measurement Resolution:
0.1µA dc
Temperature Measurement Resolution:
0.1°C
Absolute Maximum DC Voltage Measurement:
1000V dc
Width:
100mm
Battery Life:
800 h
AC Current Measurement Resolution:
0.1µA ac
Best Temperature Measurement Accuracy:
±1% + 1 °C
True RMS:
Yes
Absolute Maximum AC Voltage Measurement:
1000V ac
Model Number p:
28
Resistance Measurement Resolution:
100mΩ
Best AC Voltage Accuracy:
±0.7% + 2 Digits
Absolute Maximum AC Current Measurement:
10A ac
Maximum Frequency:
20kHz
Absolute Maximum Capacitance Measurement:
9.999F
Battery Type:
AA x 3
Absolute Maximum Resistance Measurement:
50MΩ
Maximum Operating Temperature:
+55°C
Best Capacitance Measurement Accuracy:
±1% + 2 Digits
Minimum Operating Temperature:
-15°C
Safety Category Level:
CAT III, CAT IV
Length:
198.1mm
Absolute Maximum Temperature Measurement:
+1090°C
Absolute Maximum DC Current Measurement:
10A dc
Display Type:
Digital
Best DC Current Accuracy:
±0.2% + 2 Digits
Weight:
698.5g
AC Voltage Measurement Resolution:
0.1mV ac
Best AC Current Accuracy:
±1% + 2 Digits
Safety Category Voltage:
600 V, 1000V
Multimeter Type:
Handheld
Height:
63.5mm
Best Resistance Measurement Accuracy:
± 0.2% + 1 Digit
Best DC Voltage Accuracy:
±0.05% + 1 Digit
DC Voltage Measurement Resolution:
0.1mV dc
Functions Measured:
AC Current, AC Voltage, Capacitance, DC Current, DC Voltage, Diode, Frequency, Resistance, Temperature
