Dimensions:
265 x 302 x 107mm
Capacitance Measurement Resolution:
0.001nF
DC Current Measurement Resolution:
10nA dc
Temperature Measurement Resolution:
0.1°C
Absolute Maximum DC Voltage Measurement:
1000V dc
Width:
302mm
AC Current Measurement Resolution:
10nA ac
Best Temperature Measurement Accuracy:
2 °C
True RMS:
Yes
Model Number p:
IDM8342
Resistance Measurement Resolution:
10mΩ
Best AC Voltage Accuracy:
0.35 %
Absolute Maximum AC Current Measurement:
10A ac
Maximum Frequency:
1MHz
Absolute Maximum Capacitance Measurement:
50µF
Absolute Maximum AC Voltage Measurement:
750V ac
Absolute Maximum Resistance Measurement:
50MΩ
Maximum Operating Temperature:
+50°C
Best Capacitance Measurement Accuracy:
±2% + 4 Digits
Minimum Operating Temperature:
0°C
AC Voltage Measurement Resolution:
10µV ac
Length:
265mm
Absolute Maximum Temperature Measurement:
+300°C
Absolute Maximum DC Current Measurement:
10A dc
Display Type:
Digital
Best DC Current Accuracy:
±0.05% + 4 Digits
Weight:
2.9kg
Safety Category Level:
CAT II, CAT III, CAT IV
Best AC Current Accuracy:
±0.5% + 20 Digits
Safety Category Voltage:
600V
Multimeter Type:
Bench
Height:
107mm
Best Resistance Measurement Accuracy:
±0.1% + 3 Digits
Best DC Voltage Accuracy:
±0.02% + 4 Digits
DC Voltage Measurement Resolution:
10µV dc
Functions Measured:
AC Current, AC Voltage, Capacitance, Continuity, DC Current, DC Voltage, Diode Test, Frequency, Resistance, Temperature
