Width:
48mm
Height:
150mm
Length:
70mm
Weight:
255g
True RMS:
No
Calibrated:
UKAS
Dimensions:
70 x 48 x 150mm
Battery Type:
9V
Display Type:
Digital
Model Number p:
RS12
Multimeter Type:
Handheld
Maximum Frequency:
60Hz
Functions Measured:
AC Voltage, DC Current, DC Voltage, Resistance
Safety Category Level:
CAT II, CAT III
Safety Category Voltage:
600 V, 1000V
Best AC Voltage Accuracy:
±1.2% + 10 Digits
Best DC Current Accuracy:
±1% + 2 Digits
Best DC Voltage Accuracy:
±0.5% + 2 Digits
Maximum Operating Temperature:
+50°C
Minimum Operating Temperature:
0°C
AC Voltage Measurement Resolution:
0.1V ac
DC Current Measurement Resolution:
1µA dc
DC Voltage Measurement Resolution:
0.1mV dc
Resistance Measurement Resolution:
100mΩ
Best Resistance Measurement Accuracy:
±0.8% + 2 Digits
Absolute Maximum AC Voltage Measurement:
600V ac
Absolute Maximum DC Current Measurement:
10A dc
Absolute Maximum DC Voltage Measurement:
600V dc
Absolute Maximum Resistance Measurement:
2MΩ
