Width:
90mm
Height:
183mm
Length:
45mm
Weight:
350g
True RMS:
Yes
Dimensions:
183 x 90 x 45mm
Battery Type:
1.5 V AAA
Connectivity:
Bluetooth
Display Type:
Digital
Model Number p:
RS-9519BT
Multimeter Type:
Handheld
Safety Category:
CAT III 1000 V, CAT IV 600V
Maximum Frequency:
10MHz
Functions Measured:
AC Current, AC Voltage, Capacitance, Continuity, DC Current, DC Voltage, Diode, Duty Cycle, Frequency, Resistance, Temperature
Safety Category Level:
CAT III, CAT IV
Safety Category Voltage:
600 V, 1000V
Best AC Current Accuracy:
±1.5%+8
Best AC Voltage Accuracy:
±1.0%+5
Best DC Current Accuracy:
±1.5%+8
Best DC Voltage Accuracy:
±0.8%+5
Maximum Operating Temperature:
+40°C
Minimum Operating Temperature:
0°C
AC Current Measurement Resolution:
0.01A
AC Voltage Measurement Resolution:
1V
DC Current Measurement Resolution:
0.01A
DC Voltage Measurement Resolution:
1V
Resistance Measurement Resolution:
0.01MΩ
Capacitance Measurement Resolution:
0.01mF
Temperature Measurement Resolution:
+20 °C→+1000°C
Best Resistance Measurement Accuracy:
±2.5%+10
Best Capacitance Measurement Accuracy:
±2.5%+20
Best Temperature Measurement Accuracy:
±1.5 °C+3 °C
Absolute Maximum AC Current Measurement:
10A ac
Absolute Maximum AC Voltage Measurement:
1000V ac
Absolute Maximum DC Current Measurement:
10A dc
Absolute Maximum DC Voltage Measurement:
1000V dc
Absolute Maximum Resistance Measurement:
60MΩ
Absolute Maximum Capacitance Measurement:
99.99mF
Absolute Maximum Temperature Measurement:
+1000°C
