Dimensions:
2 x 1.25 x 1mm
Mounting Type:
Surface Mount
Package Type:
SC-70
Minimum Operating Temperature:
-40 °C
Maximum Operating Temperature:
+85 °C
Pin Count:
6
Channel-to-Channel Matching (ΔRon):
60mOhm
HTSUS:
8542.39.0001
RoHS Status:
ROHS3 Compliant
Operating Temperature:
-40°C ~ 85°C (TA)
Package / Case:
6-TSSOP, SC-88, SOT-363
Switch Time (Ton, Toff) (Max):
35ns, 15ns
Current - Leakage (IS(off)) (Max):
2nA (Typ)
Voltage - Supply, Dual (V±):
-
-3db Bandwidth:
300MHz
REACH Status:
REACH Unaffected
Multiplexer/Demultiplexer Circuit:
2:1
Package:
Tape & Reel (TR)
Channel Capacitance (CS(off), CD(off)):
12pF
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Voltage - Supply, Single (V+):
1.65V ~ 5.5V
standardLeadTime:
29 Weeks
Switch Circuit:
SPDT
Number of Circuits:
1
Mounting Type:
Surface Mount
Series:
-
Crosstalk:
-70dB @ 1MHz
On-State Resistance (Max):
1.15Ohm
Supplier Device Package:
SC-88 (SC-70-6)
Charge Injection:
20pC
Base Product Number:
FSA4157
ECCN:
EAR99
