Typical Input Voltage Noise Density:
22nV/√Hz
Typical Gain Bandwidth Product:
1.4MHz
Dimensions:
10.5 x 5.45 x 1.85mm
Mounting Type:
Surface Mount
Typical Slew Rate:
1.4V/µs
Power Supply Type:
Dual, Single
Number of Channels per Chip:
2
Rail to Rail:
No
Maximum Operating Frequency:
100 kHz
Height:
1.85mm
Typical Single Supply Voltage:
40 V
Width:
5.45mm
Length:
10.5mm
Package Type:
SOIC
Minimum Operating Temperature:
-40 °C
Amplifier Type:
Power
Typical Voltage Gain:
100 dB
Maximum Operating Temperature:
+125 °C
Pin Count:
16
HTSUS:
8542.33.0001
RoHS Status:
ROHS3 Compliant
Current - Output / Channel:
1 A
Operating Temperature:
-40°C ~ 125°C
Package / Case:
16-SOIC (0.295", 7.50mm Width)
Current - Input Bias:
100 nA
Voltage - Input Offset:
1 mV
Voltage - Supply Span (Max):
40 V
Voltage - Supply Span (Min):
5 V
REACH Status:
REACH Unaffected
Output Type:
-
Current - Supply:
5mA
Package:
Tape & Reel (TR)
Moisture Sensitivity Level (MSL):
3 (168 Hours)
Slew Rate:
1.4V/µs
standardLeadTime:
30 Weeks
Number of Circuits:
2
Gain Bandwidth Product:
1.4 MHz
Mounting Type:
Surface Mount
Series:
-
Supplier Device Package:
16-SOIC
Amplifier Type:
Power
Base Product Number:
TCA0372
ECCN:
EAR99
