Series:
OBD1000
IP Rating:
IP67, IP69, IP69K
Interface:
IO-Link
Output Type:
NPN/PNP
Light Source:
LED
Sensor Style:
Block
Mounting Type:
Panel Mount
Response Time:
500 μs
Standards Met:
CE, cULus, E 87056, EN 60947-5-2:2007, EN 61131-9:2013, EN 62471:2008, IEC 60947-5-2:2007, IEC 61131-9:2013, UL 60947-5-2: 2014
Terminal Type:
4 Pin Connector
Detection Type:
Diffuse
Detection Range:
2 mm → 1 m
Maximum Current:
100 mA
Housing Material:
PC
Maximum DC Voltage:
30V
Electrical Connection:
M8 4 Pin Connector
Communication Protocol:
IO-LINK
Maximum Operating Temperature:
+60°C
Minimum Operating Temperature:
-40°C
Maximum Current:
100 mA
Standards Met:
CE, cULus, E 87056, EN 60947-5-2:2007, EN 61131-9:2013, EN 62471:2008, IEC 60947-5-2:2007, IEC 61131-9:2013, UL 60947-5-2: 2014
Mounting Type:
Panel Mount
IP Rating:
IP67, IP69, IP69K
Minimum Operating Temperature:
-40°C
Series:
OBD1000
Electrical Connection:
M8 4 Pin Connector
Detection Type:
Diffuse
Output Type:
NPN/PNP
Housing Material:
PC
Detection Range:
2 mm → 1 m
Communication Protocol:
IO-LINK
Sensor Style:
Block
Interface:
IO-Link
Response Time:
500 μs
Maximum DC Voltage:
30V
Maximum Operating Temperature:
+60°C
Terminal Type:
4 Pin Connector
Light Source:
LED
