Program Capacity:
1000 Blocks (without macro), Upto 64 macros (256 blocks each)
Dimensions:
124.6 x 90 x 60.4 mm
Voltage Category:
24 V dc
Communication Port Type:
Modbus RS485 with accessory
Width:
90mm
Input Type:
Analogue, Digital
For Use With:
em4 Series
Network Type:
Modbus with accessory
Number of Inputs:
16
Output Type:
Relay, Static
Maximum Operating Temperature:
+60°C
Programming Language Used:
Function Block, Sequential Function Chart
Number of Outputs:
10
Length:
124.6mm
Manufacturer Series:
em4 Local
Number of Communication Ports:
1
Programming Interface:
USB
Output Current:
500 mA, 6/8 A
Mounting Type:
Panel Mount
Depth:
60.4mm
Battery Backup:
Yes
Minimum Operating Temperature:
-20°C
Display Included:
Yes
HTSUS:
8537.10.9160
RoHS Status:
RoHS Compliant
Number of Outputs and Type:
10 - PWM/Solid State (2), Relay (8)
Operating Temperature:
-20°C ~ 60°C
Memory Size:
2K Octets
Approval Agency:
CE, cULus
Mounting Type:
Chassis Mount, DIN Rail
Number of Characters Per Row:
18, 18, 18, 18
REACH Status:
REACH Unaffected
Package:
Box
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Communications:
USB
standardLeadTime:
3 Weeks
Software:
em4 Soft
Display Type:
LCD - White Characters, Backlight
Ingress Protection:
IP40
Features:
-
Weight:
0.784 lb (355.62 g)
Number of Inputs and Type:
16 - Digital (4), Analog/Digital (12)
Series:
em4, B26
Voltage - Supply:
24VDC
Expandable:
Non-Expandable
ECCN:
EAR99
