Program Capacity:
368 bits
Number of Outputs:
10
Display Included:
Yes
Dimensions:
100 x 71.2 x 68 mm
Mounting Type:
DIN Rail
Minimum Operating Temperature:
-20°C
Length:
100mm
Output Type:
Solid State
Manufacturer Series:
Millenium 3
Communication Port Type:
Serial, USB
Width:
71.2mm
Depth:
68mm
Supply Voltage:
24 V dc
Input Type:
Digital
Number of Communication Ports:
2
Programming Language Used:
Ladder Logic
Programming Interface:
Front Panel
Maximum Operating Temperature:
+55°C
Output Current:
12 A
Number of Inputs:
16
HTSUS:
8537.10.9170
RoHS Status:
RoHS Compliant
Number of Outputs and Type:
10 - PWM (4), Solid State (6)
Operating Temperature:
-20°C ~ 70°C
Memory Size:
368 Bits/200 Words
Approval Agency:
CE, CSA, GL, UL
Mounting Type:
Chassis Mount, DIN Rail
Number of Characters Per Row:
18, 18, 18, 18
REACH Status:
REACH Unaffected
Package:
Bulk
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Communications:
-
standardLeadTime:
3 Weeks
Software:
M3 Soft
Display Type:
LCD - White Characters, Backlight
Ingress Protection:
IP40
Features:
Battery Backup (Lithium)
Weight:
-
Number of Inputs and Type:
16 - Digital (10), Analog/Digital (6)
Series:
Millenium 3, XD26
Voltage - Supply:
24VDC
Expandable:
Expandable
ECCN:
EAR99
