Number of Outputs:
10
Display Included:
Yes
Dimensions:
124.6 x 100 x 59.5 mm
Mounting Type:
DIN Rail
Minimum Operating Temperature:
-20°C
Length:
124.6mm
Output Type:
Transistor
Manufacturer Series:
Millenium 3
Communication Port Type:
Serial, USB
Width:
100mm
Depth:
59.5mm
Supply Voltage:
24 V dc
Input Type:
Analogue, Digital
Number of Communication Ports:
2
Programming Language Used:
FBD, Ladder Logic
Maximum Operating Temperature:
+55°C
Output Current:
500 mA
Number of Inputs:
16
HTSUS:
8537.10.9170
RoHS Status:
RoHS Compliant
Number of Outputs and Type:
10 - PWM (4), Solid State (6)
Operating Temperature:
-20°C ~ 55°C
Memory Size:
368 Bits/200 Words
Approval Agency:
CE, CSA, GL, UL
Mounting Type:
Chassis Mount, DIN Rail
Number of Characters Per Row:
18, 18, 18, 18
REACH Status:
REACH Unaffected
Package:
Box
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Communications:
-
standardLeadTime:
3 Weeks
Software:
M3 Soft
Display Type:
LCD - Black Characters, Green Backlight
Ingress Protection:
IP40
Features:
Battery Backup (Lithium)
Weight:
-
Number of Inputs and Type:
16 - Digital (10), Analog/Digital (6)
Series:
Millenium 3, XD26
Voltage - Supply:
24VDC
Expandable:
Expandable
ECCN:
EAR99
