Number of Outputs:
4
Display Included:
Yes
Dimensions:
71.5 x 58 x 90 mm
Manufacturer Series:
easy
Number of Inputs:
4 (Analogue), 8 (Digital)
Length:
71.5mm
Output Type:
Relay
Width:
58mm
Depth:
90mm
Supply Voltage:
12 V dc, 24 V dc
Input Type:
Analogue, Digital
For Use With:
easyE4
Network Type:
Ethernet
Programming Language Used:
Easy Programming EDP, Function Block Diagram (FBD), Ladder Diagram (LD), Structured Text (ST)
Maximum Operating Temperature:
+55°C
Minimum Operating Temperature:
-25°C
Standards Met:
CSA C22.2 No.61010, cULus acc. to UL 61010, EN 50178, EN 61000-6-2, EN 61000-6-3, EN 61010, IEC 60068-2-27, IEC 60068-2-30, IEC 60068-2-6, IEC 61131-2
