Pitch:
5mm
Series:
DFK-MSTB
Current:
12A
Voltage:
32 V
Row Pitch:
5mm
Mount Type:
Feed Through
Product Type:
Pluggable Terminal Block
Contact Gender:
Male
Number of Rows:
1
Contact Plating:
Tin
Tail Pin Length:
9.3mm
Connector System:
COMBICON MSTB 2.5
Contact Material:
Copper Alloy
Housing Material:
Polyamide
Termination Type:
Solder
Mating Pin Length:
9.3mm
Number of Contacts:
7
Standards/Approvals:
IEC 60512-13-5, IEC 60068-2-82, IEC 60512-5-1, IEC 60664-1, IEC 60068-2-70, UL 94 V0, JEDEC JESD 201, REACH, RoHS, cULus, CSA, CHINA RoHS, IEC 60512-1-2, EN 60695-2-12, VDE, EN ISO 22479, EN 60695-2-13, IEC 60512-3-1, IEC 60512-15-1, IEC 60512-1-1, EN 60695-10-2, IEC 60112
Maximum Operating Temperature:
105°C
Minimum Operating Temperature:
-40°C
