Actual Diameter:
0.079" (2.00mm ID), 0.252" (6.40mm OD)
HTSUS:
8536.69.4040
RoHS Status:
ROHS3 Compliant
Mounting Feature:
-
Thread Size:
-
Operating Temperature:
-20°C ~ 70°C
Industry Recognized Mating Diameter:
2.10mm ID (0.083"), 5.50mm OD (0.217")
Internal Switch(s):
Single Switch, Normally Closed
Shielding:
Unshielded
Voltage - Rated:
48V
Insulation Color:
-
REACH Status:
REACH Unaffected
Includes:
-
Number of Positions/Contacts:
2 Conductors, 3 Contacts
Material Flammability Rating:
UL94 V-0
Package:
Tape & Reel (TR)
Gender:
Male
Connector Type:
Jack
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Body Material:
Copper Alloy
Termination:
Solder
standardLeadTime:
16 Weeks
Current Rating (Amps):
5.5 A
Housing Material:
Polyamide (PA9T), Nylon 9T
Body Color:
Black
Ingress Protection:
-
Features:
Board Guide
Mounting Type:
Surface Mount, Right Angle
Mating Length/Depth:
-
Series:
-
Contact Material - Plating:
Silver
Contact Material:
Brass
ECCN:
EAR99
