Life:
100000 cycles
Depth:
47.7mm
Height:
27mm
Length:
21mm
Series:
Harmony Relay RXM
Latching:
No
Coil Power:
1.2W
Dimensions:
21 x 27 x 47.7mm
Coil Voltage:
24V ac
Mounting Type:
Plug In
Standards Met:
CE, CSA, EN/IEC, GOST, Lloyd's, REACH, RoHS Compliant, UL
Terminal Type:
Plug In
Coil Resistance:
180Ω
Number of Poles:
4
Contact Material:
Silver Alloy
Switching Current:
8A
Better World Product:
Yes
Contact Configuration:
4PDT
Better World Verification:
Green Premium
Isolation Coil To Contact:
2kV ac
Maximum Switching Power AC:
1.5 kVA
Maximum Switching Power DC:
168 W
Maximum Switching Voltage AC:
250V
Maximum Switching Voltage DC:
250V
Maximum Operating Temperature:
+55°C
Minimum Operating Temperature:
-40°C
Better World Verification:
Green Premium
Better World Product:
Yes
Standards Met:
CE, CSA, EN/IEC, GOST, Lloyd's, REACH, RoHS Compliant, UL
Mounting Type:
Plug In
Coil Power:
1.2W
Latching:
No
Coil Voltage:
24V ac
Length:
21mm
Height:
27mm
Switching Current:
8A
Depth:
47.7mm
Maximum Switching Voltage AC:
250V
Maximum Switching Power DC:
168 W
Maximum Switching Power AC:
1.5 kVA
Contact Configuration:
4PDT
Number of Poles:
4
Terminal Type:
Plug In
Coil Resistance:
180Ω
